Flight 23+ Liter Class S Automatic Sterilizer 110V

The Clave23+ Chamber Autoclave is a Class S Steam Sterilizer that utilizes the most state-of-the-art technology in steam pulsing sterilization. The Clave23+ uses a pressure displacement technology that allows a more complete removal of air inside the chamber before the sterilization cycle begins . In addition, with the steam injection pressure pulsing technology it reduces maintenance, improves sterilization effectiveness and increases speed of the sterilization process.

The Clave23+ uses the highest quality components and each unit is stress tested to ensure the quality and reliability of the machine. The Clave23+ is a compact and efficient sterilizer that is suitable for any dental, veterinary, podiatry, chiropodist, tattoo, medical and beauty office.

As the name suggests this is the largest chamber autoclave offered by Flight Dental Systems at 23L in capacity.

The Clave23+ also has an air assisted drying technology which integrates a compressor for faster drying.

Programmed Cycles

Solid/Unwrapped:

•  4 Min Sterilization @ 134C = Total Time: 45 min including Drying
•  20 min Sterilization @121C = Total Time: 45 min including Drying

Wrapped:

• 10 Min @134C = Total Time: 50 min Including Drying
• 30 min @ 121C = Total Time: 50 min Including Drying

Liquid/Textile/Rubbers:

• 10 min @ 134C = Total Time: 65 min including Drying
• 30 min @ 121C = Total Time: 65 min including Drying

Maintenance Required

Daily: Clean Door Seal & Clean the External Surface

Weekly: Clean Distilled Water Reservoir & Clean Sterilization Chamber

Monthly: Clean Filter inside Chamber and Tank

Every 3/6 Months: Replace Door Seal

Every Year: Replace Silicone Tubing, filters and door Seal

Every 2 Years: Replace Battery on Main PCB that Controls Timer
