rpi parts
Showing 1–48 of 619 results
-
Misc Parts, Misc RPI Parts, New
ACTUATOR (BACK) RPI Part #MIA216
RPI Part #MIA216
OEM Part #002-0496-00/002-0564-06ACTUATOR (BACK)
- 2.7A @ 115VAC
- Includes: (1 pc) Cable Tie (12″ Black) (RPI Part #RPT375), (1 pc) Cable Tie (14″ Black) (RPI Part #RPT816), (2) 1/4″ female flag terminals, (1) 1/4″ male QC terminal, and (1 pc)
- Threadlocker 242 (RPI Part #RPA032)
Fits: Back Section
Model(s) This Part Fits: See below
Serial Number(s) This Part Fits: See below
SKU: MIA216 -
Misc Parts, Misc RPI Parts, New
Air Filter Element RPI Part #CME071
RPI Part #CME071
OEM Part #77001541AIR FILTER ELEMENT
- Size: ~1.38″ OD x 3.43″ lg.
- Used for fresh air intake
- Includes: Rubber Air Filter Cap
- RPI Advantage! PM sticker is included for recording date that filter element was replaced
- See below for quantity required for each model
Fits: Compressor Heads
Regarding quantities required
- Matrx: OL-3, OL-2000 & OL-2001 requires (2); OL-7 & OL-4000 requires (4); and OL-10 & OL-6000 requires (6)
- Midmark: P52 requires (4) & P72 requires (6)
Model(s) This Part Fits: See below
SKU: CME071 -
Misc Parts, Misc RPI Parts, New
Air Filter Element RPI Part #CMK065
RPI Part #CMK065
OEM Part #89938 / 89831AIR FILTER ELEMENT KIT
- Size: ~1.25″ OD x 3.77″ lg.
- 10 micron paper filter
- Includes: Elbow barb fitting and a PM Sticker
- See below for quantity required for each model
Regarding quantities required
- AirStar® 1 & 10 require (1)
- AirStar® 2-1, 2-2, 3, 21, 22 & 30 require (2)
- AirStar® 5 & 50 require (4)
- AirStar® 7 & 70 require (6)
Model(s) This Part Fits: See below
SKU: CMK065 -
Misc Parts, Misc RPI Parts, New
BASE CYLINDER KIT RPI Part #MIC063
RPI Part #MIC063
OEM Part #002-0001-00BASE CYLINDER KIT RPI Part #MIC063
- 2.13″ OD ~16.25″ lg. – Center hole to center hole (retracted)
- Includes: Cylinder and (6) Cable Tie (12″ Black) (RPI Part #RPT375)
Fits: Table Base
Model(s) This Part Fits: See below
Serial Number(s) This Part Fits: See below
SKU: MIC063 -
-
-
Misc Parts, Misc RPI Parts, New
CAST CUTTER BLADE (PiN) RPI PART STB056
RPI Part #STB056
OEM Part #940-23CAST CUTTER BLADE (PiN)
- For both plaster and synthetic casts
- Size: 2.36″ oval blade
- Material: Plasma ion nitride treated stainless steel
- Color: Matte grey
- Also available: Cast Cutter Blade (RPI Part #STB043), Cast Cutter Blade (TiN) (RPI Part #STB045) and Blade Guard (RPI Part #STG042)
Fits: Head Assembly
Model(s) This Part Fits: See below
SKU: STB056 -
-
Misc Parts, Misc RPI Parts, New
Coalescing Filter Element RPI Part #CMK024
RPI Part #CMK024
OEM Part ##ACA86050; 648-00209; 77005005; 77005009FILTER ELEMENT
- Wilkerson® brand
- Type C; 0.01 micron
- Size: 1.59″ OD x 2.05″ lg.
- Includes: Filter Element, Seal, (1 pc) Bowl O-Ring (RPI Part #RPO676), and PM sticker
- RPI Advantage! PM sticker is included and can be attached to Assembly for recording date that filter was replaced.
Fits:Coalescing Filter Assembly (5 oz.)
Model(s) This Part Fits: See below
SKU: CMK024 -
Misc Parts, Misc RPI Parts, New
Compressor PM Kit RPI Part #CMK143
RPI Part #CMK143
OEM Part #87353COMPRESSOR PM KIT
- For oil-less quad headed compressors
- See Notes below for parts included in this kit
- All parts also sold separately
Includes:
- Filter Element (RPI Part #CME102)
- Filter Element (RPI Part #CME103)
- (4) Air Filter Element Kit (RPI Part #CMK065)
- PM Sticker
- PM Checklist
Model(s) This Part Fits: See below
SKU: CMK143 -
Misc Parts, Misc RPI Parts, New
Compressor PM Kit RPI Part #CMK144
RPI Part #CMK144
OEM Part #87354COMPRESSOR PM KIT
- For oil-less six headed compressors
- See Notes below for parts included in this kit
- All parts also sold separately
Includes:
- (2) Filter Element (RPI Part #CME102)
- (2) Filter Element (RPI Part #CME103)
- (6) Air Filter Element Kit (RPI Part #CMK065)
- PM Sticker
- PM Checklist
Model(s) This Part Fits: See below
SKU: CMK144 -
Misc Parts, Misc RPI Parts, New
DELIVERY VALVE RPI PART #SDV010
RPI Part #SDV010
OEM Part #28-53786-001DELIVERY VALVE
- 24 VDC; 2 Way N.C.; 6-1/2″ lg. wire leads with connector
- Includes: (2) FKM gaskets
- Included in: PM-2 Kit (RPI Part #SDK003)
Fits: Delivery System
Model(s) This Part Fits: See below
SKU: SDV010 -
Misc Parts, Misc RPI Parts, New
DENTAL-EZ FILTER ELEMENT RPI PART VPE114
RPI Part #VPE114
OEM Part #003550SPFILTER ELEMENT
- 5 Micron
- Size: 4.50″ OD x 5.38″ lg.
- Service Tip: Air filter life depends on vacuum usage, nature of environment and amount of aspirated material. Inspect air filter every 1,000 hours and replace every 2,000 hours or when visibly dirty.
- Includes: PM Sticker
- Included in: Filter Kit (RPI Part #VPK113) & Filter Kit (RPI Part #VPK117)
Fits: Vacuum Controller Assembly
Model(s) This Part Fits: See below
SKU: VPE114 -
Misc Parts, Misc RPI Parts, New
DENTAL-EZ FILTER ELEMENT RPI PART VPE116
RPI Part #VPE116
OEM Part #310705OIL FILTER ELEMENT
- Size: .78″ OD x 1.62″ lg.
- Material: 200 Mesh stainless steel and 2 Nitrile (Buna N) O-rings
- Inspect the oil filter every 1,000 hours and change the oil filter element every 2,000 hours or when changing the oil.
- Includes: PM Sticker
- Included in: Filter Kit (RPI Part #VPK113) and Filter Kit (RPI Part #VPK117)
- Also available: Synthetic Oil (Mobil 1®) (RPI Part #VPL131) and Synthetic Oil (Mobil 1®) (Case of 12) (RPI Part #VPL132)
Fits: Vacuum Controller Assembly
Model(s) This Part Fits: See below
SKU: VPE116 -
Misc Parts, Misc RPI Parts, New
DENTAL-EZ PM FILTER KIT RPI PART VPK113
RPI Part #VPK113
OEM Part #003740PM FILTER KIT
- See Service Tip below
- Includes: Filter Element (RPI Part #VPE114), Filter Element (RPI Part #VPE115), Oil Filter Element (RPI Part #VPE116), PM Sticker and PM Checklist.
- Also available: Synthetic Oil (Mobil 1®) (RPI Part #VPL131) and Synthetic Oil (Mobil 1®) (Case of 12) (RPI Part #VPL132)
Model(s) This Part Fits: See below
SKU: VPK113 -
Misc Parts, Misc RPI Parts, New
DENTAL-EZ PM FILTER KIT RPI PART VPK117
RPI Part #VPK117
OEM Part #003750PM FILTER KIT
- See Service Tip below
- Includes: Filter Element (RPI Part #VPE114), Oil Filter Element (RPI Part #VPE116), Filter Element (RPI Part #VPE118), PM Sticker and PM Checklist.
- Also available: Synthetic Oil (Mobil 1) (RPI Part #VPL131) and Synthetic Oil (Mobil 1) (Case of 6) (RPI Part #VPL132)
Fits: Vacuum Controller Assembly
Model(s) This Part Fits: See below
SKU: VPK117 -
1730E Parts (RPI), 1730EK Parts (RPI), 2340E Parts (RPI), 2340EA Parts (RPI), 2340EKA Parts (RPI), 2540E Parts (RPI), 2540EA Parts (RPI), 2540EKA Parts (RPI), 3850EHS Parts, EZ10 Parts (RPI), EZ10k Parts (RPI), EZ9 Parts (RPI), New, Tuttnauer Parts RPI
DIAGNOSTIC SMART KIT RPI Part #TUK108
1730E Parts (RPI), 1730EK Parts (RPI), 2340E Parts (RPI), 2340EA Parts (RPI), 2340EKA Parts (RPI), 2540E Parts (RPI), 2540EA Parts (RPI), 2540EKA Parts (RPI), 3850EHS Parts, EZ10 Parts (RPI), EZ10k Parts (RPI), EZ9 Parts (RPI), New, Tuttnauer Parts RPIDIAGNOSTIC SMART KIT RPI Part #TUK108
RPI Part #TUK108
OEM Part #TEST-9DIAGNOSTIC SMART KIT®
- Calibrate/verify displayed pressure values.
- Calibrate/verify the Temperature Sensor values.
- Check and monitor all test point values from the AJUNC or ANL boards.
- Kit includes a durable plastic case and troubleshooting information and usage booklet.
- See Notes below for parts included in this kit
- For SDS, please see link below
Model(s) This Part Fits: 1730E, 1730EK, 2340E, 2340EA, 2340EKA, 2540E, 2540EA, 2540EKA, 3870EHS, EZ10, EZ10k, EZ9
SKU: TUK108 -
Misc Parts, Misc RPI Parts, New
Filter Element RPI Part #CME103
RPI Part #CME103
OEM Part #87366FILTER ELEMENT
Size: ~1.12″ OD x 2.74″ lg.
2 micron paper filter
Includes: Filter element, inner O-Ring, (1 pc) Bowl O-Ring (RPI Part #RPO830), and PM StickerFits: Top Membrane Dryer Assembly (Air Techniques Part #87175)
Model(s) This Part Fits: See below
SKU: CME103 -
Misc Parts, Misc RPI Parts, New
HOUSING SEAL RPI PART STS053
RPI Part #STS053
OEM Part #(OEM Part # Not Available)HOUSING SEAL
- Size: 1/2″ wide x 28.0″ lg. x 1/8″ thk.
- Material: Black closed cell foam with PSA backing
- Includes: Installation template
- Also available: Lid Seal (RPI Part #STS054)
Fits: Chassis
Model(s) This Part Fits: See below
SKU: STS053 -
Misc Parts, Misc RPI Parts, New
INLET VALVE RPI PART #SDV047
RPI Part #SDV047
OEM Part #28-51428-002INLET VALVE
- Manifold mount
- 24VDC, 10W (59-61 Ω); 22″ lg. wire with Molex connector
- Material: Viton®/FKM seals
- Included in: PM-1 Kit (RPI Part #SDK058), PM-2 Kit (RPI Part #SDK059), Valve Manifold Assembly (RPI Part #SDA048) and Valve Manifold Assembly (RPI Part #SDA082)
- Also available: Valve Manifold (RPI Part #SDM081), Transition Valve (RPI Part #SDV046), Spanner Nut (RPI Part #ILS014) and Double Ended Spanner Wrench (RPI Part #RPT501)
Fits: Vaporizer/Condenser Assembly
Model(s) This Part Fits: See below
SKU: SDV047 -
Misc Parts, Misc RPI Parts, New
LAMP RPI Part #LMP609
RPI Part #LMP609
OEM Part #041.709.00/041.179.00/041.179.01/28.1004.00 (Bulb & Holder only)LAMP (17V, 95W)
- Base: G6.35 2-Pin
- Halogen
- Bulb Shape: T-4
- Also available: Lamp Socket Assembly (RPI Part #ADS125)
Fits:
Light Socket Assembly
Model(s) This Part Fits: See below
SKU: LMP609 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK (Fits New and Old Style!) INSTRUMENT TRAY (LARGE) RPI Part #MIT207 OEM Part #002-0374-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK (Fits New and Old Style!) INSTRUMENT TRAY (LARGE) RPI Part #MIT207 OEM Part #002-0374-00
RPI Part #MIT207
OEM Part #002-0374-00INSTRUMENT TRAY ( LARGE)
- Size: 7″ x 12″
- Can be used in wire or sheet metal style racks.
- Included in: Rack and Tray Kit (RPI Part #MIK204)
- Also available: Rack (RPI Part #MIR208), Instrument Tray (Small) (RPI Part #MIT206) and Tray Plate (RPI Part #MIP205)
Fits: Tray Rack
Model(s) This Part Fits: M9
SKU: MIT207 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK (Fits New and Old Style!) INSTRUMENT TRAY (SMALL) RPI Part #MIT206 OEM Part #002-0253-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK (Fits New and Old Style!) INSTRUMENT TRAY (SMALL) RPI Part #MIT206 OEM Part #002-0253-00
RPI Part #MIT206
OEM Part #002-0253-00INSTRUMENT TRAY (SMALL)
- Size: 6″ x 12″
- Material: Stainless steel
- Can be used in wire or sheet metal style racks.
- Included in: Rack and Tray Kit (RPI Part #MIK204)
- Also available: Rack (RPI Part #MIR208), Instrument Tray (Large) (RPI Part #MIT207) and Tray Plate (RPI Part #MIP205)
Fits: Tray Rack
Model(s) This Part Fits: M9
SKU: MIT206 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK (Fits New and Old Style!) RACK AND TRAY KIT RPI Part #MIK204
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK (Fits New and Old Style!) RACK AND TRAY KIT RPI Part #MIK204
RPI Part #MIK204
OEM Part #030-0710-01 (Tray Rack), 050-3691-00 (Tray Rack), 002-0253-00 (Instrument Tray (Small)), 002-0374-00 (Instrument Tray (Large)), 050-1773-00 (Tray Plate)RACK AND TRAY KIT
- Includes: Tray Rack (RPI Part #MIR208), (2) Instrument Tray (Small) (RPI Part #MIT206), (2) Instrument Tray (Large) (RPI Part #MIT207), and Tray Plate (RPI Part #MIP205)
- Also available: Mid-Clean 16 oz. Bottle (RPI Part #MIC143), Sci-Dry (2 oz.) Bottle (RPI Part #SCA054) and Cleaning Kit (RPI Part #RPK791)
SKU: MIK204 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK (Fits New and Old Style!) TRAY RACK RPI Part #MIR208 OEM Part #030-0710-01, 050-3691-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK (Fits New and Old Style!) TRAY RACK RPI Part #MIR208 OEM Part #030-0710-01, 050-3691-00
RPI Part #MIR208
OEM Part #030-0710-01, 050-3691-00TRAY RACK
- Material: Stainless steel
- Accommodates old and new style instrument trays.
- Included in: Rack and Tray Kit (RPI Part #MIK204)
- Also available: Instrument Tray (Small) (RPI Part #MIT206), Instrument Tray (Large) (RPI Part #MIT207) and Tray Plate (RPI Part #MIP205)
Fits: Chamber
Model(s) This Part Fits: M9
SKU: MIR208 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark Autoclave Parts, New
MIDMARK (New Style) DISPLAY ASSEMBLY RPI Part #MIA147 OEM Part #015-1550-00, 015-1550-02
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark Autoclave Parts, NewMIDMARK (New Style) DISPLAY ASSEMBLY RPI Part #MIA147 OEM Part #015-1550-00, 015-1550-02
RPI Part #MIA147
OEM Part #015-1550-00, 015-1550-02DISPLAY ASSEMBLY
Fits: Top Cover (newer style units)
Includes:
- Display (LCD) (RPI Part # MID148)
- Display Driver PC Board (RPI Part # MIB149)
- Ribbon Cable (RPI Part # MIC150)
- (2) Mounting Screws
Models This Part Fits:
- M9-020 thru -022
- M9D-020 thru -022
- M11-020 thru -022
- M11D-020 thru -022
Also available:
- Suppression Core (RPI Part # RPC762)
- Touch Pad (RPI Part # MIP099)
SKU: MIA147 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK (New Style) DOOR HANDLE RPI Part #MIH163 OEM Part #053-1253-00
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK (New Style) DOOR HANDLE RPI Part #MIH163 OEM Part #053-1253-00
RPI Part #MIH163
OEM Part #053-1253-00DOOR HANDLE
- Includes: Handle, (2) Screws (#10-24 X .375 lg) and (2) retaining washer (#10)
- See Notes below for Models this part fits
Fits: Door (newer style units)
Model(s) This Part Fits: M11, M11D, M9, M9DNotes:
Model This Part Fits:
- M9-020 thru -022
- M9D-020 thru -022
- M11-020 thru -022
- M11D-020 thru -022
SKU: MIH163 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark COVER PLATE (PRINTER) RPI #MIC199 OEM Part #050-1775-00
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark COVER PLATE (PRINTER) RPI #MIC199 OEM Part #050-1775-00
RPI Part #MIC199
OEM Part #050-1775-00COVER PLATE (PRINTER)
- Includes: (2 pc) Screw (#8 x 5/8″) (RPI Part #RPH856)
- Included in: Top Cover Kit (RPI Part #MIK196)
Fits: Top Cover
Model(s) This Part Fits: M9, M9DNotes:
Models This Part Fits:
- M9-001 thru -019
- M9D-001 thru -019
SKU: MIC199 -
M11 - Parts (RPI), M9 - Parts (RPI), Midmark Autoclave Parts, New
Midmark DISPLAY OVERLAY RPI Part #MIP098 OEM Part #061-0272-01
M11 - Parts (RPI), M9 - Parts (RPI), Midmark Autoclave Parts, NewMidmark DISPLAY OVERLAY RPI Part #MIP098 OEM Part #061-0272-01
RPI Part #MIP098
OEM Part #061-0272-01DISPLAY OVERLAY
- Adhesive backing
- Included in: Top Cover Kit (RPI Part #MIK196 & RPI Part #MIK197)
- See Notes below for models this part fits
Fits: Top Cover (older style units)
Model(s) This Part Fits: M11, M9Models This Part Fits:
- M9-001 thru -019
- M11-001 thru -019
SKU: MIP098 -
M11 - Parts (RPI), M9 - Parts (RPI), Midmark, Midmark Autoclave Parts
MIDMARK DISPLAY PC BOARD RPI Part #MIB115 OEM Part #002-0369-02/015-0646-00 (Cable only)/002-0369-00 (Display PC Board only)
M11 - Parts (RPI), M9 - Parts (RPI), Midmark, Midmark Autoclave PartsMIDMARK DISPLAY PC BOARD RPI Part #MIB115 OEM Part #002-0369-02/015-0646-00 (Cable only)/002-0369-00 (Display PC Board only)
RPI Part #MIB115
OEM Part #002-0369-02/015-0646-00 (Cable only)/002-0369-00 (Display PC Board only)DISPLAY PC BOARD
- Includes: (6) Screws (#6-32 X 3/8″) (RPI Part #AIS170) – for older style units with thread inserts and (6) Screw (#6 x 3/8″) (RPI Part #RPH852) – for newer style units
- This PC Board is HumiSeal® conformal coated
- Also available: Display PC Board Gasket (RPI Part # MIG116)
- Also available: Display Assembly (RPI Part #MIA147) for M9, M9D. M11 & M11D (-020 thru -022)
- See Notes below for models this part fits
Fits: Top Cover
Model(s) This Part Fits: M11, M9Notes:
Models This Part Fits:
- M9-001 thru -019
- M11-001 thru -019
SKU: MIB115 -
M11 - Parts (RPI), M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark DOOR MOTOR ASSEMBLY RPI #MIA180
M11 - Parts (RPI), M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark DOOR MOTOR ASSEMBLY RPI #MIA180
RPI Part #MIA180
OEM Part #002-0790-00DOOR MOTOR ASSEMBLY
- 120 VAC
- Warning Do not move the actuator arm on this motor. Moving it may damage the motor. The actuator will automatically reset to the home position as soon as power is applied during the installation process.
Fits: Chamber Frame
Model(s) This Part Fits: M11, M9:
- M9-020 thru -022
- M11-020 thru -022
SKU: MIA180 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark DOOR SPRING RPI Part #MIS076 OEM Part #050-2347-00
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark DOOR SPRING RPI Part #MIS076 OEM Part #050-2347-00
RPI Part #MIS076
OEM Part #050-2347-00DOOR SPRING
- 2 per package
- Stainless steel
- Note: (2) springs makes it easier to open chamber door
Fits: Chamber
Model(s) This Part Fits: M11, M11D, M9, M9D
Notes:
Service Tip: Install (2) springs to help in door opening process.
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M9D-001 thru -019
- M9D-020 thru -022
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: MIS076 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark ELBOW BARB FITTING RPI Part #RPF684 OEM Part #014-0258-00
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark ELBOW BARB FITTING RPI Part #RPF684 OEM Part #014-0258-00
RPI Part #RPF684
OEM Part #014-0258-00ELBOW BARB FITTING
- 1/2″ MPT x 3/4″ barb
- Material: Black Nylon®
- Also available: Safety Valve 35 PSI (RPI Part #PCV052) and Safety Valve 40 PSI (RPI Part #MIV090)
- See Notes below for models this part fits
Fits: Safety Valve (35 PSI) and Safety Valve (40 PSI)
Model(s) This Part Fits: M11, M11D, M9, M9DNotes:
Models This Part Fits:
- M9-001 thru -019 with Serial Numbers CZ1000 thru present, DA1000 thru present, DB1000 thru present, DX1000 thru present, DY1000 thru present, FD1000 thru present, & OM1000 thru present
- M9-020 thru -022 with Serial Numbers RN, RP, RR, & V1000 thru V721880
- M9D-001 thru -019 with Serial Number Prefixes FF1000 thru present & FG1000 thru present
- M9D-020 thru -022 thru Serial Number Prefixes RW, RX, & V1000 thru V721880
- M11-001 thru -019 with Serial Numbers ES1000 thru present, ET1000 thru present, FP1000 thru present, FR1000 thru present, & GB1000 thru present
- M11-020 thru -022 with Serial Number Prefixes RS, RT, RV, & V1000 thru V721880
- M11D-001 thru -019 with Serial Numbers GC1000 thru present & GD1000 thru present
- M11D-020 thru -022 with Serial Number Prefixes RY, RZ, & V1000 thru V721880
SKU: RPF684 -
M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark FIBER GASKET (7/16″) RPI Part #RPG925 OEM Part #H98137
M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark FIBER GASKET (7/16″) RPI Part #RPG925 OEM Part #H98137
RPI Part #RPG925
OEM Part #H98137FIBER GASKET (7/16″)
- 6 per package
- Material: Green fiber/rubber compound; 750 ˚F max
- Size: .457″ ID x .688″ OD x .062″ thk
- Included in: Heater Mounting Hardware (RPI Part #RCH119)
- See Notes below for Models this part fits
Fits: Heater Bushing
Model(s) This Part Fits: M11, M11D, M7, M9, M9DNotes:
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M9D-001 thru -019
- M9D-020 thru -022
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: RPG925 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark FILL/VENT VALVE ASSEMBLY RPI Part #MIA137 OEM Part #029-2755-00/002-1362-00
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark FILL/VENT VALVE ASSEMBLY RPI Part #MIA137 OEM Part #029-2755-00/002-1362-00
RPI Part #MIA137
OEM Part #029-2755-00/002-1362-00FILL/VENT VALVE ASSEMBLY
- Piston Style Valves
- Material: Brass body and fittings, Viton solenoid seat
- 120 VAC 50/60Hz. FWR; 14W
- See NOTES for Serial # breakdown below.
Fits: Fill/Vent Valve Assembly
Model(s) This Part Fits: M11, M11D, M9, M9DNotes:
Also Includes:
- Solenoid Valve (Fill) (RPI Part # MIV138)
- Solenoid Valve (Vent) (RPI Part # MIV139)
- Manifold Assembly (RPI Part # MIA096)
Models This Part Fits:
- M9-020 thru -022
- M9D-020 thru -022
- M11-020 thru -022
- M11D-020 thru -022
SKU: MIA137 -
7 - Parts (RPI), M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark HEATER MOUNTING HARDWARE RPI Part #RCH119 OEM Part #002-1350-00
7 - Parts (RPI), M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark HEATER MOUNTING HARDWARE RPI Part #RCH119 OEM Part #002-1350-00
RPI Part #RCH119
OEM Part #002-1350-00MIDMARK HEATER MOUNTING HARDWARE
- Includes: (2) Fiber Gasket (RPI Part #RPG925), (2) Stainless Steel Flat Washer, (2) Stainless Steel Internal Tooth Washer, (2) 7/16-20 Brass Jam Nut, and (2) 7/16-28 Brass Jam Nut
- Included in: (RPI Part #MIH048, RPI Part #MIH049 & RPI Part #RCH118)
- This Hardware Kit includes two sets of Brass Jam Nuts. Use the 7/16-20 Brass Jam Nuts on the RPI Heater only, and use the 7/16-28 Brass Jam Nuts on the OEM Heater only.
- See Notes below for Models this part fits
Fits: Chamber/Heater
Model(s) This Part Fits: 7, M11, M11D, M7, M9, M9DModels This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M9D-001 thru -019
- M9D-020 thru -022
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: RCH119 -
M11 - Parts (RPI), Midmark Autoclave Parts, New
MIDMARK M11 (New Style) DISPLAY ASSEMBLY RPI Part #MIA147
M11 - Parts (RPI), Midmark Autoclave Parts, NewMIDMARK M11 (New Style) DISPLAY ASSEMBLY RPI Part #MIA147
RPI Part #MIA147
OEM Part #015-1550-00, 015-1550-02Midmark M11 DISPLAY ASSEMBLY
Fits: Top Cover (newer style units)
Includes:
- Display (LCD) RPI Part # MID148
- Display Driver PC Board RPI Part # MIB149
- Ribbon Cable RPI Part # MIC150
- (2) Mounting Screws
More Midmark M11 RPI Parts Available →
SKU: MIA147-M11 -
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 (Old Style) DOOR HANDLE RPI #MIH162 OEM Part #053-0909-00
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M11 (Old Style) DOOR HANDLE RPI #MIH162 OEM Part #053-0909-00
RPI Part #MIH162
OEM Part #053-0909-00DOOR HANDLE
- Includes: Handle (2) Screw (#10-24 X .375″ lg.) and (2) retaining washer (#10)
- Included in: Door Panel Kit (RPI Part #MIK195)
- See Notes below for model this part fits
Fits: Door (Older style units)
Model(s) This Part Fits: M11- M11-001 thru -019
SKU: MIH162 -
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 AIR VENT BELLOWS ASSEMBLY RPI #RCB089
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M11 AIR VENT BELLOWS ASSEMBLY RPI #RCB089
RPI Part #RCB089
OEM Part #002-0375-00/014-0193-00MIDMARK M11 AIR VENT BELLOWS ASSEMBLY
- 1/4” compression fittings both ends
- Material: Bronze diaphragm style; Stainless steel housing
- Mount to tubing between temperature gauge and reservoir
- Actuates within 12°F of saturated steam temperature
See below for serial numbers this part fits
SKU: RCB089-M11 -
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 DAM GASKET RPI Part #MIG036 OEM Part #002-0504-00
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M11 DAM GASKET RPI Part #MIG036 OEM Part #002-0504-00
RPI Part #MIG036
OEM Part #053-0904-00 / 002-0504-00 (Door and Dam Gasket)DAM GASKET
- Material: Silicone Rubber
- Also included in Sterilizer PM Kit (RPI Part #MIK080)
- Redesigned to channel water back into the chamber and its easier to install!
- See Notes below
Fits: Mounts above Door Gasket
Notes: Replace the Door Gasket at the same time… Use RPI PM Kit (RPI Part #MIK080) or (RPI Part #MIG028)
Models This Part Fits:
- M11-020 thru -022
- M11D-001 thru -019
SKU: MIG036 -
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 DOOR GASKET RPI Part #MIG028 OEM Part #053-0527-00/002-0504-00
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M11 DOOR GASKET RPI Part #MIG028 OEM Part #053-0527-00/002-0504-00
RPI Part #MIG028
OEM Part #053-0527-00/002-0504-00DOOR GASKET
- Size: ~12.875″ OD
- Material: Silicone rubber
- Included in: Sterilizer PM Kit (RPI Part #MIK080)
- See Notes below
Fits: Door
Model(s) This Part Fits: M11, M11D
Notes:
Also Available:
- Sterilizer PM Kit (RPI Part #MIK080)
- Dam Gasket (RPI Part #MIG036)
Models This Part Fits:
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: MIG028 -
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 DOOR MOTOR ASSEMBLY RPI #MIA180
RPI Part #MIA180
OEM Part #002-0790-00DOOR MOTOR ASSEMBLY
- 120 VAC
- Warning Do not move the actuator arm on this motor. Moving it may damage the motor. The actuator will automatically reset to the home position as soon as power is applied during the installation process.
Fits: Chamber Frame
Model(s) This Part Fits: M11-020 thru -022
SKU: MIA180-M11 -
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 DOOR PANEL KIT RPI Part #MIK195 OEM Part #002-0506-00/002-0506-01
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M11 DOOR PANEL KIT RPI Part #MIK195 OEM Part #002-0506-00/002-0506-01
RPI Part #MIK195
OEM Part #002-0506-00/002-0506-01DOOR PANEL KIT
- Includes: Door Handle (RPI Part #MIH162), (4 pc) Screw (#8 x 7/8″) (RPI Part #RPH855), and Steam Block (RPI Part #MIB140)
- See Notes below for Model this part fits
Fits: Door Frame
Model(s) This Part Fits: M11
SKU: MIK195 -
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M11 DOOR SPRING RPI Part #MIS076
RPI Part #MIS076
OEM Part #050-2347-00Midmark M11 DOOR SPRING
- 2 per package
- Stainless steel
- Note: (2) springs makes it easier to open chamber door
Fits: Chamber
Models This Part Fits:
- M11-001 thru -019
- M11-020 thru -022
Service Tip: Install (2) springs to help in door opening process.
More Midmark M11 RPI Parts Available →
SKU: MIS076-M11 -
M11 - Parts (RPI), Midmark Autoclave Parts, New
Midmark M11 FILL/VENT MESH CHAMBER FILTER RPI Part #MIF062 OEM Part #002-0360-00 / 016-0790-00
M11 - Parts (RPI), Midmark Autoclave Parts, NewMidmark M11 FILL/VENT MESH CHAMBER FILTER RPI Part #MIF062 OEM Part #002-0360-00 / 016-0790-00
RPI Part #MIF062
OEM Part #002-0360-00 (Mesh Style) / 016-0790-00 (Mesh Style)FILL/VENT MESH CHAMBER FILTER (STAINLESS STEEL)
- 2 per package
- Size: 30 x 30 mesh stainless steel mesh
- Can be used to filter chamber debris at fill and vent ports
- Also available: Filter (Sintered Style) (RPI Part #MIF038)
Fits: Chamber, Fill Tube and Vent Tube
Midmark • Ritter Models This Part Fits:
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: MIF062-M11 -
New, M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark M11 HEATER ELEMENT ASSEMBLY RPI Part #MIH049 OEM Part #002-0505-00
New, M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark M11 HEATER ELEMENT ASSEMBLY RPI Part #MIH049 OEM Part #002-0505-00
RPI Part #MIH049
OEM Part #002-0505-00HEATER ELEMENT ASSEMBLY
- 1425W, 120VAC, ~10Ω
- Size: 3-7/16″ W x 15-1/2″ lg.; 7/16-20 Bushings
- Includes: Heater Mounting Hardware (RPI Part #RCH119)
- Also available: Heater Harness (RPI Part #MIH135)
- See Note below for Models this part fits
Fits: Inside of chamber
Model(s) This Part Fits: M11, M11D
Notes:
Models This Part Fits:
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: MIH049 -
M11 - Parts (RPI), Midmark Autoclave Parts, New
Midmark M11 LATCH LEVER PIVOT KIT RPI Part #MIK201 OEM Part #042-0106-00/042-0106-01
M11 - Parts (RPI), Midmark Autoclave Parts, NewMidmark M11 LATCH LEVER PIVOT KIT RPI Part #MIK201 OEM Part #042-0106-00/042-0106-01
RPI Part #MIK201
OEM Part #042-0106-00/042-0106-01 (shoulder screw only)/016-0131-18 (flanged bushing only)/045-0000-04 (washer only)LATCH LEVER PIVOT KIT
- Includes: Stainless steel shoulder screw, flanged bushing, and (2) washers (for use in machines that do not use flanged bushing)
- See below for Models this part fits
Models This Part Fits:
- M11-001 thru -019
- M11-020 thru -022
SKU: MIK201-M11 -
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New, PM Kits
Midmark M11 PM KIT RPI Part #MIK080
M11 - Parts (RPI), Midmark, Midmark Autoclave Parts, New, PM KitsMidmark M11 PM KIT RPI Part #MIK080
RPI Part #MIK080
OEM Part #002-0504-00 (Door & Dam Gasket Only)Midmark M11 Sterilizer PM Kit
Includes:
- Dam Gasket (RPI Part #MIG036)
- Door Gasket (RPI Part #MIG028)
- (2 pc) Door Spring (RPI Part #MIS076)
- (2 pc) Fill/Vent Mesh Chamber Filter (RPI Part #MIF062)
- Filter (Sintered Style) (RPI Part #MIF038)
- PM Checklist and PM Sticker
Models This Part Fits: M11
- M11-001 thru -019
- M11-020 thru -022
SKU: MIK080-M11
