M9 - Parts (RPI), Midmark Autoclave Parts, New
Midmark M9 LATCH LEVER PIVOT KIT RPI Part #MIK201 OEM Part #042-0106-00/042-0106-01
M9 - Parts (RPI), Midmark Autoclave Parts, NewMidmark M9 LATCH LEVER PIVOT KIT RPI Part #MIK201 OEM Part #042-0106-00/042-0106-01
RPI Part #MIK201
OEM Part #042-0106-00/042-0106-01 (shoulder screw only)/016-0131-18 (flanged bushing only)/045-0000-04 (washer only)LATCH LEVER PIVOT KIT
- Includes: Stainless steel shoulder screw, flanged bushing, and (2) washers (for use in machines that do not use flanged bushing)
- See below for Models this part fits
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
SKU: MIK201-M9 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 M11 (New Style) SOLENOID VALVE (FILL) RPI Part #MIV138 OEM Part #002-1360-00/014-0420-02
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 M11 (New Style) SOLENOID VALVE (FILL) RPI Part #MIV138 OEM Part #002-1360-00/014-0420-02
RPI Part #MIV138
OEM Part #002-1360-00/014-0420-02SOLENOID VALVE (FILL)
- Piston Style Valve Operator Only
- Material: Viton seat; Manifold mount
- 120 VAC 50/60Hz. FWR; 14W
- Need Repair Kit? (RPI Part #RCK113)
- Need Coil? (RPI Part #RCC114)
- See Serial # breakdown below.
Fits: Manifold Block Assembly newer style units
Model(s) This Part Fits: M11, M11D, M9, M9DNotes:
Also included in:
- Fill/Vent Valve Assembly (RPI Part #MIA137)
Also available:
- Solenoid Valve (Vent) (RPI Part #MIV139)
- Manifold Block Assembly (RPI Part #MIA096)
- Spanner Nut (RPI Part #ILS014)
- Double Ended Wrench (RPI Part #RPT501)
Serial # Prefix Breakdown:
- Fits M9-020 thru -022 with Serial # prefixes RN, RP, RR & V.
- Fits M9D-020 thru -022 with Serial # prefixes RW, RX & V.
- Fits M11-020 thru -022 with Serial # prefixes RS, RT, RV & V.
- Fits M11D-020 thru -022 with Serial # prefixes RY, RZ & V.
SKU: MIV138 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 M11 (New Style) SOLENOID VALVE (VENT) RPI Part #MIV139 OEM Part #002-1361-00/014-0420-03
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 M11 (New Style) SOLENOID VALVE (VENT) RPI Part #MIV139 OEM Part #002-1361-00/014-0420-03
RPI Part #MIV139
OEM Part #002-1361-00/014-0420-03SOLENOID VALVE (VENT)
- Piston Style Valve Operator Only
- Material: Viton seat; Manifold mount; AC valve
- 120 VAC 50/60Hz. FWR; 14W
- Need Repair Kit? (RPI Part # MIK110)
- Need Coil? (RPI Part # RCC114)
- See NOTES below for Serial # breakdown
Fits: Manifold Block Assembly newer style units
Model(s) This Part Fits: M11, M11D, M9, M9DNotes:
Includes:
- Male Connector (RPI Part #RPF228)
Also Included in:
- Fill/Vent Valve Assembly (RPI Part #MIA137)
Also Available
- Solenoid Valve (Fill) (RPI Part # MIV138)
- Manifold Block Assembly (RPI Part #MIA096)
- Spanner Nut (RPI Part #ILS014)
- Double Ended Wrench (RPI Part #RPT501)
Serial # Prefix breakdown
- Fits M9-020 thru -022 with Serial # prefixes RN, RP, RR & V.
- Fits M9D-020 thru -022 with Serial # prefixes RW, RX & V.
- Fits M11-020 thru -022 with Serial # prefixes RS, RT, RV & V.
- Fits M11D-020 thru -022 with Serial # prefixes RY, RZ & V.
SKU: MIV139 -
Midmark, Midmark Autoclave Parts, New
Midmark M9 M11 DOOR SWITCH ASSEMBLY (New Style Units) RPI Part #MIS095 OEM Part #015-1556-00
Midmark, Midmark Autoclave Parts, NewMidmark M9 M11 DOOR SWITCH ASSEMBLY (New Style Units) RPI Part #MIS095 OEM Part #015-1556-00
RPI Part #MIS095
OEM Part #015-1556-00DOOR SWITCH ASSEMBLY
- Includes 11-1/2″ lg. wires with 3/16″ Quick Connect Terminals
- 5A @ 250VAC; SPDT; N.O
- See Notes below for Model the part fits
Fits: Latch Bracket (newer style units)
Model(s) This Part Fits: M11, M11D, M9, M9DNotes:
Model This Part Fits:
- M9-020 thru -022
- M9D-020 thru -022
- M11-020 thru -022
- M11D-020 thru -022
More Midmark RPI Parts Available →
SKU: MIS095 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark Autoclave Parts, New
Midmark M9 M11 DOOR SWITCH ASSEMBLY (Old Style Units) RPI Part #MIS039 OEM Part #002-0362-00
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark Autoclave Parts, NewMidmark M9 M11 DOOR SWITCH ASSEMBLY (Old Style Units) RPI Part #MIS039 OEM Part #002-0362-00
RPI Part #MIS039
OEM Part #002-0362-00DOOR SWITCH ASSEMBLY
- See Notes below for Models this part fits
- 0.1A@125/250 VAC; SPDT; N.O.
- Includes all parts as shown
Fits: Switch weldment (older style units)
Model(s) This Part Fits: M11, M11D, M9, M9D
Notes:
Models This Part Fits:
- M9-001 thru -019
- M9D-001 thru -019
- M11-001 thru -019
- M11D-001 thru -019
SKU: MIS039 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 M11 STANDOFF RPI Part #MIS146 OEM Part #053-0295-01
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9 M11 STANDOFF RPI Part #MIS146 OEM Part #053-0295-01
FREE SHIPPING!!!
Midmark M9 M11 STANDOFF RPI Part #MIS146
- 4 Per Package
More Midmark M9 parts available →
More Midmark M9D parts available →
SKU: MIS146 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 OS Solenoid Valve (FILL) RPI Part #MIS046
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 OS Solenoid Valve (FILL) RPI Part #MIS046
RPI Part #MIS046
OEM Part #014-0200-00M9 SOLENOID VALVE (FILL)
- Manifold mount; AC valve
- 1/4″ orifice; 1/2-20 THD
- 120VAC/ 60Hz., 10W
- Need Repair Kit? RPI Part #MIK056
- Need Coil? RPI Part #MIC060
Fits: Older style units
Model This Part Fits:
- Fits M9-001 thru -019 with Serial #’s CZ1000 thru CZ1109.
SKU: MIS046 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 OS Solenoid Valve (VENT) RPI Part #MIS045
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 OS Solenoid Valve (VENT) RPI Part #MIS045
RPI Part #MIS045
OEM Part #014-0199-00M9 SOLENOID VALVE (VENT)
- Manifold mount; AC valve
- 1/8″ orifice; 5/16-24 THD
- 120VAC/ 60Hz., 7W
- Includes O-rings
- Need Repair Kit? RPI Part #MIK055
- Need Coil? RPI Part #MIC059
Fits: Older style units
Model This Part Fits:
- Fits M9-001 thru -019 with Serial #’s CZ1000 thru CZ1109.
SKU: MIS045 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 POWER CORD RPI Part #RPC291 OEM 015-0640-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9 POWER CORD RPI Part #RPC291 OEM 015-0640-00
RPI Part #RPC291
OEM Part #015-0640-00POWER CORD (15A @ 125VAC, LEFT ANGLE, 6 ft.)
- Length: 6 ft.
- 14/3 SJT, 105˚C, 15A @ 125VAC
- Plug Type: NEMA; 5-15P
- Connector Type: EN60320-C13L Left Angle
- Color: Black
- For use with Snap-In AC Receptacle (RPI Part #RPR290) and (RPI Part #RPR583)
Fits: Power Entry Filter module
Model(s) This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
SKU: RPC291-M9 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 PRINTER CARTRIDGE RPI #MIC226
RPI Part #MIC226
OEM Part #053-0505-00Midmark M9 PRINTER CARTRIDGE
- Epson® brand ribbon cartridge; Color: Black
- See below for models this part fits
Fits: M9 Printers (Old Style and New Style)
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
SKU: MIC226-M9 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 PULSE SOLENOID (Old Style Units) RPI Part #MIS044 OEM Part #002-0363-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9 PULSE SOLENOID (Old Style Units) RPI Part #MIS044 OEM Part #002-0363-00
RPI Part #MIS044
OEM Part #002-0363-00PULSE SOLENOID
- Single wound coil 120V/60Hz.; Black Coil
- Includes all parts as shown
- 3/16″ tabs
- Stroke: 1/2″; ~11.6 Ω
- Pull type solenoid
- See below for M9 Models this part fits
Fits: Door Latch Mounting Bracket (older style units)
Models This Part Fits:
- M9-001 thru -019 with Serial # prefixes CZ, DA, DB, DX, DY, FD & OM
Also Available:
- Latch Lever Pivot Kit (RPI Part #MIK201)
More Midmark M9 RPI Parts Available →
SKU: MIS044 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 Repair Kit (FILL VALVE) RPI Part #MIK056
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 Repair Kit (FILL VALVE) RPI Part #MIK056
RPI Part #MIK056
M9 REPAIR KIT (FILL VALVE)
- Manifold mount; AC valve
- 1/4″ orifice; 1/2-20 THD
- 120VAC/ 60Hz., 10W
- Need Valve? RPI Part #MIS046
- Need Coil? RPI Part #MIC060
Fits: Manifold mount vent solenoid valve older style units.
Model This Part Fits:
- Fits M9-001 thru -019 with Serial #’s CZ1000 thru CZ1109.
SKU: MIK056 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 Repair Kit (VENT VALVE) RPI Part #MIK055
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 Repair Kit (VENT VALVE) RPI Part #MIK055
RPI Part #MIK055
M9 REPAIR KIT (FILL VALVE)
- Manifold mount; AC valve
- Includes all parts as shown
- Need Valve? RPI Part #MIS045
- Need Coil? RPI Part #MIC059
Fits: Manifold mount vent solenoid valve older style units.
Model This Part Fits:
- Fits M9-001 thru -019 with Serial #’s CZ1000 thru CZ1109.
SKU: MIK055 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 SOLENOID VALVE (AIR VALVE) (New Style Units) RPI Part #MIV118
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9 SOLENOID VALVE (AIR VALVE) (New Style Units) RPI Part #MIV118
RPI Part #MIV118
OEM Part #014-0419-00Midmark M9 ( SOLENOID VALVE (AIR VALVE)
- 120VAC / 60 Hz. FWR; 1/8″ orifice; 1/8 FPT; Port
- Brass body; Viton seats; Non-Manifold mount
- High Temperature coil: 180˚C (350˚F)
- Need Repair Kit? RPI Part #MIK119
- Need Coil only? RPI Part #MIC120
- See Notes below for Serial #’s this part fits
Fits: Air Valve newer style units
Model(s) This Part Fits: M9Notes: CHECK SERIAL NUMBERS HERE:
Fits M9-020 thru -022 with Serial # prefixes RN, RP, RR & V.
SKU: MIV118-M9 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 SOLENOID VALVE (VENT) RPI Part #MIS043 OEM Part #002-0366-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9 SOLENOID VALVE (VENT) RPI Part #MIS043 OEM Part #002-0366-00
RPI Part #MIS043
OEM Part #002-0366-00SOLENOID VALVE (VENT)
- Non-manifold mount; Mounts on Chasis; AC valve
- 1/8″ orifice, 1/8″ FPT ports; 120VAC, 60Hz., 7W
- Included in: Fill/Vent Manifold Kit (RPI Part #MIK202)
- Also available: Repair Kit (Vent Valve) (RPI Part #MIK054), Coil (Vent Valve) (RPI Part #MIC058), Spanner Nut (RPI Part #ILS014) and Double Ended Wrench (RPI Part #RPT501)
- See Notes below for models this part fits
Fits: Older Style Units and Fill/Vent Manifold
Model(s) This Part Fits: M11, M9
Notes:
Models This Part Fits:
- M9-001 thru -019
- M11-001 thru -019
SKU: MIS043-M9 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 Spring Arm RPI Part #MIA086
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 Spring Arm RPI Part #MIA086
RPI Part #MIA086
MIDMARK M9 Spring Arm
- Stainless Steel
Fits: Switch Bracket
Model This Part Fits:
- M19 (Older style without motor assembly)
- M9-001 thru -019
- M9D-001 thru -019
SKU: MIA086 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9 Sterilizer PM Kit RPI Part #MIK158
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9 Sterilizer PM Kit RPI Part #MIK158
RPI Part #MIK158
MIDMARK M9 Sterilizer PM Kit
- ONLY FITS: Door WITH Metal Flap (OEM #030-0698-00)
- Important Note: The Door Gasket included in this Kit has been engineered to eliminate the need for the OEM’s metal ring. The OEM’s metal ring should not be used with this Gasket.
- All parts also sold separately (See Notes below for parts included in this Kit)
- Also available: Sterilizer PM Kit (RPI Part #MIK072) for door without metal flap; Door Insulator Pad (RPI Part #MIP040); Mid-Clean™ (RPI Part #MIC143); and, Cleaning Kit (RPI Part #RPK791)
Fits: Door with Metal Flap
Model This Part Fits:
- M9-001 thru -019
- M9D-001 thru -019
Parts Included:
- See Below
SKU: MIK158 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 TEMPERATURE PROBE ASSEMBLY (NEW STYLE UNITS) RPI Part #MIS121
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 TEMPERATURE PROBE ASSEMBLY (NEW STYLE UNITS) RPI Part #MIS121
RPI Part #MIS121
OEM Part #015-1680-00M9 TEMPERATURE SENSOR
- Range: 1.07KΩ to 1.1KΩ @ 25˚C (Positive Temperature Coefficient)
- Material: Stainless steel housing; 1/4″ MPT
- Wires: 18-1/2″ lg.
- Also available: Temperature Probe Assembly (RPI Part #MIP050)
Fits: Rear Chamber Port (newer style units)
Model This Part Fits:
- M9-020 thru -022
SKU: MIS121-M9 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts
MIDMARK M9 TOUCH PAD (NEW STYLE UNITS) RPI Part #MIP099 OEM Part #015-1550-00/015-1551-00
M9 - Parts (RPI), Midmark, Midmark Autoclave PartsMIDMARK M9 TOUCH PAD (NEW STYLE UNITS) RPI Part #MIP099 OEM Part #015-1550-00/015-1551-00
RPI Part #MIP099
OEM Part #015-1550-00/015-1551-00TOUCH PAD
- Adhesive backing
- See below for Models this part fits
Fits: Top Cover (newer style units)
Model(s) This Part Fits: M9
- M9-020 thru -022
SKU: MIP099-M9 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 Vent Valve Coil RPI Part #MIC059
RPI Part #MIC059
M9 VENT VALVE COIL
- Manifold mount; AC Valve
- 180˚ C 271 – 318Ω
- 120VAC/ 60Hz.
- Valve Also available: RPI Part #MIS045
Fits:Vent solenoid valve assembly (manifold mount) older style units
Model This Part Fits:
- M9-001 thru -019 with Serial #’s CZ1000 thru CZ1109
SKU: MIC059 -
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9 WATER LEVEL SENSOR ASSEMBLY RPI Part #MIS075 OEM Part #002-0358-00
M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9 WATER LEVEL SENSOR ASSEMBLY RPI Part #MIS075 OEM Part #002-0358-00
RPI Part #MIS075
OEM Part #002-0358-00WATER LEVEL SENSOR ASSEMBLY
- Includes: Compression Nut with Ferrule (RPI Part # RCN059)
- Also Available: Water Level Sensor Harness (RPI Part # MIH136)
- See Below for Model this part fits
Fits: Chamber
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
SKU: MIS075-M9 -
Accessories / Supplies, M9 - Parts (RPI), M9D - Parts (RPI), Midmark Autoclave Parts, New
Midmark M9® Hose Clip RPI RPC283
Accessories / Supplies, M9 - Parts (RPI), M9D - Parts (RPI), Midmark Autoclave Parts, NewMidmark M9® Hose Clip RPI RPC283
FREE SHIPPING!!!
Midmark M9® Hose Clip RPI RPC283
Pack of 5 hose clips
Midmark • Ritter Models This Part Fits:
- M9-001 thru -019
- M9D-001 thru -019
- M9-020 thru -022: Serial Numbers V2200 thru V1464209
- M9D-020 thru -022: Serial Numbers V2200 thru V1464209
More Midmark M9 parts available →
More Midmark M9D parts available →
SKU: RPC283-M9 -
M9D - Parts (RPI), Midmark Autoclave Parts, New
MIDMARK M9D (New Style) DISPLAY ASSEMBLY RPI Part #MIA147
M9D - Parts (RPI), Midmark Autoclave Parts, NewMIDMARK M9D (New Style) DISPLAY ASSEMBLY RPI Part #MIA147
RPI Part #MIA147
OEM Part #015-1550-00, 015-1550-02Midmark M9D DISPLAY ASSEMBLY
Fits: Top Cover (newer style units)
Includes:
- Display (LCD) RPI Part # MID148
- Display Driver PC Board RPI Part # MIB149
- Ribbon Cable RPI Part # MIC150
- (2) Mounting Screws
SKU: MIA147-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D AIR VENT BELLOWS ASSEMBLY RPI #RCB089
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D AIR VENT BELLOWS ASSEMBLY RPI #RCB089
RPI Part #RCB089
OEM Part #002-0375-00/014-0193-00MIDMARK M9D AIR VENT BELLOWS ASSEMBLY
- 1/4” compression fittings both ends
- Material: Bronze diaphragm style; Stainless steel housing
- Mount to tubing between temperature gauge and reservoir
- Actuates within 12°F of saturated steam temperature
See below for serial numbers this part fits
More Midmark M9D RPI Parts Available →
SKU: RCB089-M9D -
Autoclave Cleaners, M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D Autoclave Cleaner RPI Part #MIC143
Autoclave Cleaners, M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D Autoclave Cleaner RPI Part #MIC143
RPI Part #MIC143
OEM Part #002-0396-00 (Speed Clean)MID-CLEAN™
- Sterilizer cleaning solution
- (1) 16 oz. bottle
- Please see the (Safety Data Sheet) for this part. (Adobe PDF)
- Also available: Mid-Clean™ case of 12 bottles (RPI Part #MIC144)
More Midmark M9D RPI Parts Available →
SKU: MIC143-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D DAM GASKET RPI PART MIG035 OEM Part #053-0508-00
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D DAM GASKET RPI PART MIG035 OEM Part #053-0508-00
RPI Part #MIG035
OEM Part #053-0508-00/053-0903-00(Dam Gasket)/002-0361-00(Door & Dam Gasket) /002-0361-01(Door & Dam Gasket)DAM GASKET
- Material: Silicone Rubber
- Only fits: Door without metal flap (OEM #030-1016-00)
- Also included in: Sterilizer PM Kit (RPI Part #MIK072)
- Also available: Dam Gasket (RPI Part #MIG157) for door with metal flap
- Redesigned to channel water back into the chamber and its easier to install!
- See NOTES below
Fits: Door without metal flap (OEM Part #030-1016-00)
Model(s) This Part Fits: M9, M9D
Notes: Replace the door gasket at the same time… Use the RPI PM Kit (RPI Part #MIK072) or (RPI Part #MIG027)
Models This Part Fits:
- M9D-001 thru -019
- M9D-020 thru -022
SKU: MIG035-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D DOOR SPRING RPI Part #MIS076
RPI Part #MIS076
OEM Part #050-2347-00Midmark M9D DOOR SPRING
- 2 per package
- Stainless steel
- Note: (2) springs makes it easier to open chamber door
Fits: Chamber
Models This Part Fits:
- M9D-001 thru -019
- M9D-020 thru -022
Service Tip: Install (2) springs to help in door opening process.
More Midmark M9D RPI Parts Available →
SKU: MIS076-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D DOOR SWITCH ASSEMBLY (New Style Units) RPI Part #MIS095 OEM Part #015-1556-00
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D DOOR SWITCH ASSEMBLY (New Style Units) RPI Part #MIS095 OEM Part #015-1556-00
RPI Part #MIS095
OEM Part #015-1556-00Midmark M9D DOOR SWITCH ASSEMBLY
- Includes 11-1/2″ lg. wires with 3/16″ Quick Connect Terminals
- 5A @ 250VAC; SPDT; N.O
- See Notes below for Model the part fits
Fits: Latch Bracket (newer style units)
Model This Part Fits:
- M9D-020 thru -022
More Midmark M9D RPI Parts Available →
SKU: MIS095-M9D -
M9D - Parts (RPI), Midmark Autoclave Parts, New
Midmark M9D FILL/VENT MESH CHAMBER FILTER RPI Part #MIF062 OEM Part #002-0360-00 / 016-0790-00
M9D - Parts (RPI), Midmark Autoclave Parts, NewMidmark M9D FILL/VENT MESH CHAMBER FILTER RPI Part #MIF062 OEM Part #002-0360-00 / 016-0790-00
RPI Part #MIF062
OEM Part #002-0360-00 (Mesh Style) / 016-0790-00 (Mesh Style)FILL/VENT MESH CHAMBER FILTER (STAINLESS STEEL)
- 2 per package
- Size: 30 x 30 mesh stainless steel mesh
- Can be used to filter chamber debris at fill and vent ports
- Also available: Filter (Sintered Style) (RPI Part #MIF038)
- See Notes below:
Fits: Chamber, Fill Tube and Vent Tube
Midmark • Ritter Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M9D-001 thru -019
- M9D-020 thru -022
SKU: MIF062-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D FILL/VENT VALVE ASSEMBLY RPI Part #MIA137
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D FILL/VENT VALVE ASSEMBLY RPI Part #MIA137
RPI Part #MIA137
OEM Part #029-2755-00/002-1362-00Midmark M9D FILL/VENT VALVE ASSEMBLY
- Piston Style Valves
- Material: Brass body and fittings, Viton solenoid seat
- 120 VAC 50/60Hz. FWR; 14W
- See NOTES for Serial # breakdown below.
Fits: Fill/Vent Valve Assembly
Model(s) This Part Fits: M9, M9DNotes:
Also Includes:
- Solenoid Valve (Fill) (RPI Part # MIV138)
- Solenoid Valve (Vent) (RPI Part # MIV139)
- Manifold Assembly (RPI Part # MIA096)
Models This Part Fits:
- M9-020 thru -022
- M9D-020 thru -022
SKU: MIA137-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D POWER CORD RPI Part #RPC291 OEM 015-0640-00
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D POWER CORD RPI Part #RPC291 OEM 015-0640-00
RPI Part #RPC291
OEM Part #015-0640-00POWER CORD (15A @ 125VAC, LEFT ANGLE, 6 ft.)
- Length: 6 ft.
- 14/3 SJT, 105˚C, 15A @ 125VAC
- Plug Type: NEMA; 5-15P
- Connector Type: EN60320-C13L Left Angle
- Color: Black
- For use with Snap-In AC Receptacle (RPI Part #RPR290) and (RPI Part #RPR583)
Fits: Power Entry Filter module
Model(s) This Part Fits:
- M9D-001 thru -019
- M9D-020 thru -022
SKU: RPC291-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark M9D SOLENOID VALVE (AIR VALVE) (New Style Units) RPI Part #MIV118
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark M9D SOLENOID VALVE (AIR VALVE) (New Style Units) RPI Part #MIV118
RPI Part #MIV118
OEM Part #014-0419-00Midmark M9D ( SOLENOID VALVE (AIR VALVE)
- 120VAC / 60 Hz. FWR; 1/8″ orifice; 1/8 FPT; Port
- Brass body; Viton seats; Non-Manifold mount
- High Temperature coil: 180˚C (350˚F)
- Need Repair Kit? RPI Part #MIK119
- Need Coil only? RPI Part #MIC120
- See Notes below for Serial #’s this part fits
Fits: Air Valve newer style units
Model(s) This Part Fits: M9DNotes: CHECK SERIAL NUMBERS HERE:
Fits M9D-020 thru -022 with Serial # prefixes RW, RX & V.
SKU: MIV118-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9D TEMPERATURE PROBE ASSEMBLY (NEW STYLE UNITS) RPI Part #MIS121
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9D TEMPERATURE PROBE ASSEMBLY (NEW STYLE UNITS) RPI Part #MIS121
RPI Part #MIS121
OEM Part #015-1680-00M9D TEMPERATURE SENSOR
- Range: 1.07KΩ to 1.1KΩ @ 25˚C (Positive Temperature Coefficient)
- Material: Stainless steel housing; 1/4″ MPT
- Wires: 18-1/2″ lg.
- Also available: Temperature Probe Assembly (RPI Part #MIP050)
Fits: Rear Chamber Port (newer style units)
Model This Part Fits:
- M9D-020 thru -022
SKU: MIS121-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts
MIDMARK M9D TOUCH PAD (NEW STYLE UNITS) RPI Part #MIP099 OEM Part #015-1550-00/015-1551-00
M9D - Parts (RPI), Midmark, Midmark Autoclave PartsMIDMARK M9D TOUCH PAD (NEW STYLE UNITS) RPI Part #MIP099 OEM Part #015-1550-00/015-1551-00
RPI Part #MIP099
OEM Part #015-1550-00/015-1551-00TOUCH PAD
- Adhesive backing
- See below for Models this part fits
Fits: Top Cover (newer style units)
Model(s) This Part Fits: M9D
- M9D-020 thru -022
SKU: MIP099-M9D -
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK M9D WATER LEVEL SENSOR ASSEMBLY RPI Part #MIS075 OEM Part #002-0358-00
M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK M9D WATER LEVEL SENSOR ASSEMBLY RPI Part #MIS075 OEM Part #002-0358-00
RPI Part #MIS075
OEM Part #002-0358-00WATER LEVEL SENSOR ASSEMBLY
- Includes: Compression Nut with Ferrule (RPI Part # RCN059)
- Also Available: Water Level Sensor Harness (RPI Part # MIH136)
- See Below for Model this part fits
Fits: Chamber
Models This Part Fits:
- M9D-001 thru -019
- M9D-020 thru -022
SKU: MIS075-M9D -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark MAIN HARNESS RPI Part #MIH238 OEM Part #015-1554-00 (Main Harness only) 015-1640-00 (Hi Limit Jumper only)
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark MAIN HARNESS RPI Part #MIH238 OEM Part #015-1554-00 (Main Harness only) 015-1640-00 (Hi Limit Jumper only)
RPI Part #MIH238
OEM Part #015-1554-00 (Main Harness only) 015-1640-00 (Hi Limit Jumper only)MAIN HARNESS
- Includes: Both the main harness and the hi limit jumper
- See Notes below for Serial Numbers this part fits
Fits: Main Control Board
Model(s) This Part Fits: M11, M11D, M9, M9DModels This Part Fits:
- M9-020 thru -022 with Serial Number prefixes RN, RP, RR & V
- M9D-020 thru -022 with Serial Number prefixes RW, RX & V
- M11-020 thru -022 with Serial Number prefixes RS, RT, RV & V
- M11D-020 thru -022 with Serial Number prefixes RY, RZ & V
SKU: MIH238 -
M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark OVERTEMP THERMOSTAT RPI Part #MIT047 OEM Part #002-0370-00 / 015-0647-00
M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark OVERTEMP THERMOSTAT RPI Part #MIT047 OEM Part #002-0370-00 / 015-0647-00
RPI Part #MIT047
OEM Part #002-0370-00 / 015-0647-00OVERTEMP THERMOSTAT
- Automatic reset
- Opens @ 295 ±7°F
- Closes @ 240 ±12°F
- 1/4″ Tabs
- See below for Models this part fits
Fits: Bracket that mounts to under side of chamber (older style units)
Model(s) This Part Fits: M7, M9, M9D, M11, M11D- M9-001 thru -019
- M9D-001 thru -019
- M11-001 thru -019
- M11D-001 thru -019
SKU: MIT047 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New, PM Kits
Midmark PM KIT RPI Part #MIK072 OEM Part #002-0361-01
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New, PM KitsMidmark PM KIT RPI Part #MIK072 OEM Part #002-0361-01
RPI Part #MIK072
OEM Part #002-0361-01 (Door & Dam Gasket only)STERILIZER PM KIT
- All parts also sold separately (See Notes below for parts included in this Kit)
- Only fits Door without metal flap (OEM Part #030-1016-00)
- See Notes below for models this part fits
- Also available: Sterilizer PM Kit (RPI Part #MIK158) for door with metal flap
Fits: Door without metal flap (OEM Part #030-1016-00)
Model(s) This Part Fits: M9, M9DNotes:
Includes:
- Dam Gasket (RPI Part #MIG035)
- Door Gasket (RPI Part #MIG027)
- (2 pc) Door Spring (RPI Part #MIS076)
- (2 pc) Fill/Vent Mesh Chamber Filter (RPI Part #MIF062)
- Filter (Sintered Style) (RPI Part #MIF038)
- PM Checklist and PM Sticker
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M9D-001 thru -019
- M9D-020 thru -022
SKU: MIK072 -
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts, New, PM Kits
Midmark PM KIT RPI Part #MIK080 OEM Part #002-0504-00 (Door & Dam Gasket Only)
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts, New, PM KitsMidmark PM KIT RPI Part #MIK080 OEM Part #002-0504-00 (Door & Dam Gasket Only)
RPI Part #MIK080
OEM Part #002-0504-00 (Door & Dam Gasket Only)STERILIZER PM KIT
- All parts also sold separately (See Notes below for parts included in this Kit)
Includes:
- Dam Gasket (RPI Part #MIG036)
- Door Gasket (RPI Part #MIG028)
- (2 pc) Door Spring (RPI Part #MIS076)
- (2 pc) Fill/Vent Mesh Chamber Filter (RPI Part #MIF062)
- Filter (Sintered Style) (RPI Part #MIF038)
- PM Checklist and PM Sticker
Models This Part Fits: M11, M11D
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: MIK080 -
M11 - Parts (RPI), M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, New
Midmark PRINTER CARTRIDGE RPI #MIC226 OEM Part #053-0505-00
M11 - Parts (RPI), M9 - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMidmark PRINTER CARTRIDGE RPI #MIC226 OEM Part #053-0505-00
RPI Part #MIC226
OEM Part #053-0505-00PRINTER CARTRIDGE
- Epson® brand ribbon cartridge; Color: Black
- See below for models this part fits
Fits: Printers (Old Style and New Style)
Model(s): M11, M9Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M11-001 thru -019
- M11-020 thru -022
SKU: MIC226 -
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark RPI M11 Drain Hose Clip (push-in style) MIC333
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark RPI M11 Drain Hose Clip (push-in style) MIC333
RPI Part #MIC333
OEM Part #015-1695-00Midmark M11 HOSE CLIP (push-in style)
- 2 per package
- Size: 11/16″ diameter capacity, 1/2″ wide, black plastic
- Fits mounting hole size: .252″ thru .267″ dia.
Fits: Reservoir Drain Tubing to Front Panel (Newer Style Units Only)
Models This Part Fits: See Below
SKU: MIC333-M11 -
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark RPI M11 PRINTER FUSE RPF049
M11 - Parts (RPI), M11D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark RPI M11 PRINTER FUSE RPF049
RPI Part #RPF049
OEM Part #015-0346-08Midmark M11 PRINTER FUSE (3A, 250V) – 1/4 X 1-1/4 – FAST ACTING
- 5 per package
- AGC; Glass; 1/4″ dia. x 1-1/4″ lg.
- Fast-Acting
Fits: PC Board
Models This Part Fits:
- M11-001 thru -019
- M11D-001 thru -019
SKU: RPF049-M11 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark RPI M9 / M11 Drain Hose Clip (push-in style) MIC333
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark RPI M9 / M11 Drain Hose Clip (push-in style) MIC333
RPI Part #MIC333
OEM Part #015-1695-00HOSE CLIP (push-in style)
- 2 per package
- Size: 11/16″ diameter capacity, 1/2″ wide, black plastic
- Fits mounting hole size: .252″ thru .267″ dia.
Fits: Reservoir Drain Tubing to Front Panel (Newer Style Units Only)
Models This Part Fits: See Below
SKU: MIC333 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark RPI M9 Drain Hose Clip (push-in style) MIC333
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark RPI M9 Drain Hose Clip (push-in style) MIC333
RPI Part #MIC333
OEM Part #015-1695-00Midmark M9 HOSE CLIP (push-in style)
- 2 per package
- Size: 11/16″ diameter capacity, 1/2″ wide, black plastic
- Fits mounting hole size: .252″ thru .267″ dia.
Fits: Reservoir Drain Tubing to Front Panel (Newer Style Units Only)
Models This Part Fits: See Below
SKU: MIC333-M9 -
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts
Midmark RPI M9 PRINTER FUSE RPF049
M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave PartsMidmark RPI M9 PRINTER FUSE RPF049
RPI Part #RPF049
OEM Part #015-0346-08Midmark M9 PRINTER FUSE (3A, 250V) – 1/4 X 1-1/4 – FAST ACTING
- 5 per package
- AGC; Glass; 1/4″ dia. x 1-1/4″ lg.
- Fast-Acting
Fits: PC Board
Models This Part Fits:
- M9-001 thru -019
- M9D-001 thru -019
SKU: RPF049-M9 -
Midmark, Midmark Autoclave Parts, New
Midmark SOLENOID VALVE (AIR VALVE) (New Style Units) RPI Part #MIV118
Midmark, Midmark Autoclave Parts, NewMidmark SOLENOID VALVE (AIR VALVE) (New Style Units) RPI Part #MIV118
RPI Part #MIV118
OEM Part #014-0419-00SOLENOID VALVE (AIR VALVE)
- 120VAC / 60 Hz. FWR; 1/8″ orifice; 1/8 FPT; Port
- Brass body; Viton seats; Non-Manifold mount
- High Temperature coil: 180˚C (350˚F)
- Need Repair Kit? RPI Part #MIK119
- Need Coil only? RPI Part #MIC120
- See Notes below for Serial #’s this part fits
Fits: Air Valve newer style units
Model(s) This Part Fits: M11, M11D, M9, M9DNotes: CHECK SERIAL NUMBERS HERE:
Fits M9-020 thru -022 with Serial # prefixes RN, RP, RR & V.
Fits M9D-020 thru -022 with Serial # prefixes RW, RX & V.
Fits M11-020 thru -022 with Serial # prefixes RS, RT, RV & V.
Fits M11D-020 thru -022 with Serial # prefixes RY, RZ & V.SKU: MIV118 -
M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK SPANNER NUT RPI Part #ILS014 OEM Part #026169
M11 - Parts (RPI), M11D - Parts (RPI), M7 - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK SPANNER NUT RPI Part #ILS014 OEM Part #026169
RPI Part #ILS014
OEM Part #026169SPANNER NUT
- Size: .525″ ID x .875″ HEX x .250″ THK
- Material: Stainless steel
- Dimensions: .093″ dia. dowel pins at .750″ apart
- For use when repairing solenoid valves in Midmark and Pelton & Crane sterilizers, and Instrumentation Laboratories analyzers.
- Replacement end attachment for Double Ended Spanner Wrench (RPI Part #RPT501) or use as a stand alone Spanner Nut
- Also available: Double Ended Spanner Wrench (RPI Part #RPT501) and Spanner Nut (RPI Part #RPT364)
Fits: Fill, Dump and Vent Solenoid Valve / Solenoid in Valve in Gas Plumbing
Model(s) This Part Fits: Delta 10″ (AF), Delta 8″ (AE), Delta Q10, Delta Q8, Delta XL10, Delta XL8, Eagle 10 & 10 Plus, M11, M11D, M7, M9, M9D, Validator 10 (AA), Validator 8 (AB)Notes:
Service Tip: To avoid damaging the autoclave, it is recommended to use the Spanner Nut (RPI Part #ILS014) when replacing the Vent Plunger Kit (RPI Part #PCK102), Dump Plunger Kit (RPI Part #PCK106) and Fill Plunger Kit (RPI Part #PCK110)
Models This Part Fits:
- M9-001 thru -019
- M9-020 thru -022
- M9D-001 thru -019
- M9D-020 thru -022
- M11-001 thru -019
- M11-020 thru -022
- M11D-001 thru -019
- M11D-020 thru -022
SKU: ILS014 -
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, New
MIDMARK TEMPERATURE PROBE ASSEMBLY (NEW STYLE UNITS) RPI Part #MIS121 OEM Part #015-1680-00
M11 - Parts (RPI), M11D - Parts (RPI), M9 - Parts (RPI), M9D - Parts (RPI), Midmark, Midmark Autoclave Parts, NewMIDMARK TEMPERATURE PROBE ASSEMBLY (NEW STYLE UNITS) RPI Part #MIS121 OEM Part #015-1680-00
RPI Part #MIS121
OEM Part #015-1680-00TEMPERATURE SENSOR
- Range: 1.07KΩ to 1.1KΩ @ 25˚C (Positive Temperature Coefficient)
- Material: Stainless steel housing; 1/4″ MPT
- Wires: 18-1/2″ lg.
- Also available: Temperature Probe Assembly (RPI Part #MIP050)
- See Notes below for Model this part fits
Fits: Rear Chamber Port (newer style units)
Model(s) This Part Fits: M11, M11D, M9, M9D
Notes:
Model This Part Fits:
- M9-020 thru -022
- M9D-020 thru -022
- M11-020 thru -022
- M11D-020 thru -022
SKU: MIS121
